19MM & 25MM COMPACT & MALAYSIAN
(THERMOPLASTIC PIPE TYPE 1 & 2)
SHUT OFF NOZZLE | PVC | BRASS | SS
TECHNICAL SPECIFICATION
(BRANCH PIPE WITH NOZZLE)
| BIS Specification | : | IS 884 |
| Type | : | A, Swinging Type, Wall Mounted |
| Size | : | INLET 20 MM & 25 MM |
| Material of Construction | : | MS Sheet Conforming to IS 513 |
| SIDWS, Hub, Wall Bracket | : | Grade LTB2 OF IS 318 |
| Swivel Joint | : | IS 1239 (PART 1) |
| Pipe With Fittings | : | Rubber as per IS 444 or Thermoplastic as per IS 12585 Hose, Nozzle Performance IS 8090 Hydrostatic Pressures Test No Leakage at 21 Kg/cm2 Range of Throw at 7 Kg/cm2 Minimum 6 Meters Discharge at 7 kg/cm2 Minimum 24 LPM |
